Recently, Dongguan Huanyi Instrument Technology Co., Ltd. purchased an SX-L301N purification efficiency tester from Suzhou Suxin Environmental Technology Co., Ltd. after multiple inspections.
The SX-L301N high concentration particle counter is an integrated machine that combines our company's new generation 2.83L/min touchscreen particle counter with a diluter, making it convenient for users to detect particles of different concentrations in different situations.
A particle counter is a specialized instrument for testing the particle size and distribution of airborne dust particles. It has evolved from microscopes and gone through processes such as microscopes, settling tubes, settling instruments, centrifugal settling instruments, particle counters, laser air particle counters, condensation nucleus particle counters, multi-channel multifunctional particle counters, etc. Currently, it is widely used in authoritative institutions such as drug testing institutes, blood centers, epidemic prevention stations, disease prevention and control centers, and quality supervision institutes in various provinces and cities; It is also widely used in the electronics industry, pharmaceutical workshops, semiconductors, optics or precision machining, plastics, painting, hospitals, environmental protection, inspection institutes and other production enterprises and research departments.
The all-in-one machine can be used for particle detection in both purification areas and high concentration particle areas.
| Model | SX-L301N |
| Sample flow | 2.83L/min ±5% （0.1 CFM） |
| Particle size channel | 0.3μm,0.5μm,1μm,3μm,5μm,10μm |
| laser light source | Imported laser diodes from Japan with an ultra long lifespan |
| Air source | German Thomas imported air pump, continuous working flow stable, energy-saving and environmentally friendly, efficient and low-noise |
| Verification standards | JJF1190-2008，GB/T6167-2007 |
| Particle measurement repeatability relative error | <10%FS |
| Particle measurement particle size distribution error | ≤±30% |
| Saturated concentration | 3.5 × 10000 pieces/2.83L |
| Dilution ratio | 1 ∽ 100 repeatability deviation ± 10% |
| Cleanliness recovery characteristic | ≤ 10 minutes (counting to zero for 3 consecutive times within 10 minutes, 95% confidence level) |
| Sample time | Setting range: 1-14400 seconds |
| Sample delay | Setting range: 1-255 seconds |
| Sampling points (position) | Setting range: 2-9 (confidence detection) 2-50 (arithmetic mean) |
| Sampling times | Setting range: 2 to 50 |
| Working hours | Fully charged for continuous testing time of 4 hours |
| Data memory capacity | 1 to 5000 sets of measurement data, searchable |
| Screen display | Colorful 7-inch touch screen |
| Printing method | Built-in Thermal Printer |
| Built-in Lithium Battery | DC 14.8V 6.6Ah |
| Compatible charger | Input 100-240V 2A output 16.8V 5A |
| Charging power supply | AC 220V ± 10%/50Hz |
| Cleanliness level determination criteria | ISO14644-1, GMP dynamic, GMP static, UCL calculation |
| Data communication interface | USB |
| User Permissions | User parameter setting permission, query permission, data export permission |
| Environment requirement | Usage environment: Temperature 0-40 ℃, relative humidity 10-70% |
| Standard accessory | Sampling port rubber sleeve, self-cleaning filter, printing paper, portable protective box, charging adapter, export data CD, USB data cable, black hose (inner diameter 6mm), user manual, original factory calibration report, dilution factor selection table, certificate of conformity. |
| External dimensions | Length 400 x Width 300 x Height 180 (mm) |
| Material | SUS304 stainless steel |
| Weight | 6Kg |
